MOM Tag

product description

　

　　Material：Special FR4 packaging

　　Size：100x11x3.2mm

　　113x16.5x3.2mm

　　138x22x3.2mm

　　100x30x3.2mm(with magnetic)

　　100x30x3.2mm

　　95x25x3.2mm

　　97x17x3.2mm

　　36x13x2.7mm

　　Chip: H3, M4QT

　　Protocol: ISO18000-6C

　　EPC storage: 96 bit, can be extended to 480bit

　　User storage: 512 bit

　　Reading range: 1.5M to 10M

　　Working Temeperature: -20℃ - 100℃

　　Environment:ROHS compliant

　　Printing: offset

　　Mount: 3M backing layer

　　MOM tag

　　Size: 135 x 21 x 15mm / 249 x 13.8 x 6mm

　　Chip optional: Alien H4, Impinj M4/M5, NXP Ucode G2/HSL/G2XL,etc.

　　Working Temeperature: -20℃-80℃

　　Reading Range:5-10m

　　Application：Filed Electricity Power Inspection, the tower pole inspection, elevator inspection,

　　pressure vessel cylinder, Electric household appliances tracing ,etc.
